Bucket Elevator for Chicken Feed Pellet Line

Bucket Elevator

Model

Bucket Elevator

Feature

Low Consumption,Less residue

Operation

Simple Automatic Operation

Send Email

Chat now

Share With :

Description

Features

Parameters

Inquiry

Description

TDTG Bucket Elevator

Bucket elevator is independently developed by Strongwin and is a fixed installation mainly used for the vertical continuous conveying of powdery materials or granular materials. The equipment is of straightforward structure, compact design, good sealing performance, easy installation, and maintenance, allowing positive and reverse material feeding, as well as flexible process configuration and layout.

Efficiency

Affordable

Customizable

Fixed installation

Compact design

Good Sealing Performance

Application of TDTG Bucket Elevator

The vertical bucket elevator is the ideal type of conveyor for vertical handling of bulk materials and design for conveying the power, grain, and block materials, such as coal, cement, block, sand, clay, and ore.

The bucket elevator is allowed to convey materials with high temperatures when armed with a special circle chain structure.

It has the advantages of low lifting speed, less mill stock, convenient dislodging ultra-low processing wastage, and auto-tensioning of the dustpan belt.

Application

Suitable for conveying materials that are difficult to break and grade.

After installation and adjustment, we will train our customers to work how to operate;

Training worker how to maintain and protect

According to features, we will make complete maintenance rules for you, containing how to maintain, when to maintain, and who maintains)

Our company after-sale department will call you at regular intervals, ask if maintain and give advice.

Features

TDTG Bucket Elevator Features

It uses high-quality rubber.fireproofing,wear-resisting.

It can prevent dust explosion effectively safety.

With the patent technology.it can prevent blocking.

The machine barrel uses advanced craft, so it's high quality and the tightness is good .

It's weight little,wear-resisting, and well tightness.

Low elongation with special material, wear-resisting.

Selt-cleaning engine base uses variable circular plates.

The engine base.Can assemble feed hopper with two directions according to different requirements.

Stand base tensioning device adopts gravity tensioning or screw tension.

You can assemble an automatic alarm system and speed monitoring system.

Super quality of Henan Strongwin TDTG Bucket Elevator

Material thickness of main equipment is more than feed machinery standard 2mm;
The weight is heavier than feed machinery by 20%.
Output higher 20%;
The feed rate of return increases by 3-5%.

Parameters

Model	TDTG26/18	TDTG36/18	TDTG36/23	TDTG36/28	TDTG40/23	TDTG50/23
Capacity T/h	3-6t/h	6-15t/h	10-20t/h	15-30t/h	25-35t/h	30-50t/h
Power Kw	2.2kw	4kw	4/5.5kw	5.5/7.5kw	11kw	15kw
